Electronic Switch News

Electronic Switch News: Latest E-Switch Products

E-Switch has been a leading electromechanical switch provider for nearly 50 years now. We offer one of the broadest switch lines available today, and product offerings continue to expand monthly with new introductions that cater to the industrial, medical, transportation, security, telecommunication, consumer electronic and sustainable energy markets.

Customer demand and feedback is always incorporated into the latest E-Switch products, so you’ll want to keep up with the latest electronic switch news by keeping tabs on recent releases.

Electronic Switch News: E-Switch New Releases (2024)

November 2024: EGJ1210 Series Slide Switch

Egj1210aag1
  • Surface mount and through hole PC board design
  • Right angle options
  • 1.60mm travel
  • Compact design
  • 250 gram force to actuate
  • SPDT function

September 2024: PZ3 Series Anti-Vandal (Piezo Switch)

Pz3m2fnnw300
  • 16mm panel cutout
  • IP68 (in-house tested)
  • Electrical Rating: 1A, 5-24VDC
  • Momentary Pulse Function
  • 300mm wire leads with 1×2 connector housing pin
  • Electrical Life: 50 million cycles

August 2024: TL1030 Series Tact Switch

Tl1030af350aqj
  • Surface mount design
  • 3.5 x 2.9 mm size
  • Operating force options: 160, 200, 350 and 500gf
  • Up to 200,000-cycle life expectancy
  • Operating/Storage Temperature: -40°C to +85°C
  • Tape and Reel packaging (4,000 pcs/reel)

July 2024: PB350 Series Pushbutton Switch

Pb350dtrr
  • SPST or SPDT/Double action
  • Double action: first circuit closes mid travel, second at full travel
  • Long travel – 2.0mm
  • High actuation force (ST: 490 grams; DT: 1st position – 600 grams, 2nd position – 1,150 grams)
  • Tactile response
  • LED colors: red, white, yellow, blue or green

June 2024: PVHC4 Series Anti-Vandal Switch

High current switch: Pvhc4
  • Electrical Rating: 20A, 250VAC; 25A, 30VDC
  • 19mm diameter panel cutout
  • IP67 rated
  • Non-illuminated, ring or ring/power symbol illumination with LED options
  • SPST; latching or momentary function
  • 50,000-cycle electrical life

May 2024: E100 & E200 Pushbutton Switches (Emergency Stops)

E100 Both
  • IP65 rated
  • 16mm panel cutout size
  • Easy operation with a pushlock turn design to reset
  • High actuation force (2.0 kgf)
  • Illumination options (Neon, LED or incandescent)
  • Contact arrangement and rating options, along with required agency approvals

April 2024: TL1018 Series Tact Switch

Tl1018 (orange Ground Terminal)
  • Surface mount (SMT) design
  • 3.5mm x 2.6mm size
  • 160gf, 240gf, 340gf or 450gf operating force options
  • Ground terminal option
  • Up to 500,000-cycle life expectancy
  • Tape and Reel packaging

March 2024: PVB3 Series Anti-Vandal Switch

Pvb3
  • IP65 rated
  • 16mm panel cutout
  • Non-illuminated, ring illumination or ring and power symbol
  • Momentary or latching functions
  • Multiple LED color options
  • Electrical Rating: 2A, 24VDC; 0.5A, 220VAC

February 2024: KAG Series DIP Switch

Best DIP switch 2024 quality: KAG Series
  • Gullwing (SMT) termination option
  • Tube or Tape and Reel packaging options
  • Top tape seal option with recessed actuator
  • Low profile
  • 1, 2, 4, 8 or 10 positions
  • Gold contacts

January 2024: RB3 and RB5 Series Rocker Switches

Best rocker switches 2024: RB5 Series
  • IP67 rated
  • Up to 25A, 125VAC; UL, ENEC
  • Panel mount snap-in design
  • Single illumination, dual illuminated or non-illuminated options
  • Many illumination color and voltage options
  • Eight actuator marking options
